Дверь кабины HOWO (Хово) HOWO A7 61 Гр. Дверь кабины
Замок двери
| Номер на рисунке | Название в интернет-магазине | Остаток | Артикул | Кол-во в автомобиле | Название 1 | Название 2 | Примечание 1 | Примечание 2 |
|---|
| Номер на рисунке | Название в интернет-магазине | Остаток | Артикул | Кол-во в автомобиле | Название 1 | Название 2 | Примечание 1 | Примечание 2 |
|---|---|---|---|---|---|---|---|---|
| 1 | WG1664330003 | I | 左玻璃几降器总成 | Window lifter left | ||||
| 2 | WG1664330004 | 1 | 右玻璃升降器总成（与左件对称） | Window lifter right | ||||
| 3 | WG1664330015 | 1 | 左午:门玻璃(带玻璃托架） | Door glass left | ||||
| 4 | WG1664330016 | 1 | 右车门玻璃（带玻璃托架） | Door glass right | ||||
| 5 | WG1664330009 | 1 | 左前玻璃滑梢 | Glass guide left front | ||||
| 6 | WG1664330018 | 2 | 滑梢密封条II | Sealing profile II | ||||
| 7 | WG1664330011 | 1 | 左后玻璃滑梢 | Glass guide left rear | ||||
| 8 | WG1664330010 | 1 | 右前玻璃滑槽 | Glass guide right front | ||||
| 9 | WG1664330017 | 2 | 滑槽密封条I | Sealing profile I | ||||
| 10 | WG1664330012 | 1 | 右后玻璃滑槽 | Glass guide right rear | ||||
| 11 | WG1664330019 | 2 | 乍门玻璃外密封条 | Outer scaling profile | ||||
| 12 | WG1664330020 | 2 | 车门玻璃内密封条I | Inter sealing profile I | ||||
| 13 | WG1664330021 | 2 | 车门玻璃内密封n | Inter sealing profile II | ||||
| 14 | Q2140810 | 16 | 丨字梢盘头螺钉 | Screw | ||||
| 15 | Q40205 | 2 | 人垫圈 | Washer | ||||
| 16 | Q1840520 | 2 | 六炻法兰面螺栓 | Screw | ||||
| 17 | AZ1664930001 | 22 | 塑料螺母座 | plastic nut-plate | ||||
| 18 | AZ1642770017 | 2 | 支承套(扩张筒式螺钉座） | plastic nut | ||||
| 19 | WG1664330033 | 1 | 左车门音响安装板总成 | cover panel left | ||||
| 20 | WG1664330034 | 1 | 右车门竒响安装板总成 | cover panel right | ||||
| 21 | Q2713516 | 2 | 自攻螺钉 | screw | ||||
| 22 | Q2214816 | 22 | 丨字梢盘头自攻螺钉和平垫圈组合件 | screw | ||||
| 23 | AZ1664330019 | 1 | 左车门内饰板支架 | bracket left | ||||
| 24 | AZ1664330020 | 1 | 右车门内饰板支架（与左件对称） | bracket right | ||||
| 25 | Q2140816 | 4 | 十宇槽盘头螺钉 | screw | ||||
| 26 | WG1664330023 | 2 | 车门内通风翠密封条 | sealing profile | ||||
| 27 | WG1664330022 | 2 | 午:门内通风單 | breather | ||||
| 28 | WG1664330025 | 1 | 左车门内衬板总成 | Internal lining for left door | ||||
| 29 | Q174B0840 | 2 | 十字槽凹穴六角头螺栓 | screw | ||||
| 30 | WG1664330040 | 1 | 扶手外板总成一左车门 | Cover left | ||||
| 31 | Q2204816 | 3 | 丨字梢盘头自攻螺钉和平垫圈组合件 | screw | ||||
| 32 | WG1664330045 | 1 | 装饰条总成一左车n | Cover | ||||
| 33 | WG1664330051 | 1 | 内开启手柄盖板一左车门 | plug left | ||||
| 34 | Q2214816 | 3 | 卜字槽盘头自攻螺钉和平垫圈组合件 | screw | ||||
| 35 | WG1664330097 | 3 | 螺钉堵盖 | Cover | ||||
| 36 | WG1664330026 | 1 | 右车n内衬板总成 | Internal lining for right door | ||||
| 37 | Q174B0840 | 2 | 十字槽凹穴六角头螺栓 | screw | ||||
| 38 | WG1664330140 | 1 | 扶手外板总成一右车门 | Cover right | ||||
| 39 | Q2204816 | 3 | 丨字梢盘头向攻螺钉和平蛰岡绀合件 | screw | ||||
| 40 | WG1664330097 | 3 | 螺钉堵流 | Cover | ||||
| 41 | WG1664330145 | 1 | 装饰条总成一右■车门 | Cover | ||||
| 42 | WG1664330151 | 1 | 内丌启手柄if板一右车门 | pi咋 right | ||||
| 43 | Q2214816 | 3 | 卜字梢盘头自攻螺钉和平垫圈组合件 | screw | ||||
| 44 | WG丨664330005 | 1 | 左车门r装饰外板 | Outer garnish left | ||||
| 45 | WG1664330006 | 1 | 右车门下装饰外板 | Outer garnish right | ||||
| 46 | WG1664330007 | 1 | 左车门下装饰内板 | inter garnish left | ||||
| 47 | WG1664330008 | 1 | 右车门T装饰内板 | inter garnish right | ||||
| 48 | Q1840616 | 4 | 六角法兰面蟪栓 | six point socket screw | ||||
| 49 | Q1840816 | 22 | 六角法兰面螺栓 | six point socket screw | ||||
| .50 | WG1664331061 | 1 | 右车门附件控制开关面板 | control unit right | ||||
| 51 | WG1664331062 | 1 | 左车门附件控制开关面板 | control unit left | ||||
| 52 | Q2140514 | 2 | 卜宁•梢盘头螺钉 | Screw | ||||
| 53 | Q40105 | 2 | 小垫圈 | Washer | ||||
| 54 | WG1664331063 | 8 | 左车门附件控制歼关 | control unit right | ||||
| 55 | WG1664331064 | 8 | 右车门附件控制丌关 | control unit left |
