1 |
|
|
GB25-76 |
2 |
小六角头头部带孔螺栓 |
Bolt M12xl.25x50 |
|
|
|
2 |
|
|
1819 |
按需 |
铁丝 |
Iron wire |
|
|
|
3 |
|
|
16775 |
1 |
副箱拨叉 |
Sub-gearbox shifting fork |
|
|
|
4 |
|
|
14347 |
1 |
密封垫 |
Gasket |
|
|
|
5 |
|
|
16778 |
1 |
范围档气缸 |
Gear range cylinder |
|
|
|
6 |
|
|
GB5793-76 |
8 |
弹簧垫圈10 |
Bolt Ml〇x32 |
|
|
|
7 |
|
|
GB21-76 |
8 |
小六角头螺栓M10X32 |
Gear range shifting forkshaft |
|
|
|
8 |
|
|
14765 |
I |
〇型密封圈 |
O-ring |
|
|
|
9 |
|
|
16993 |
1 |
范围档拨叉轴 |
Gear range shifting forkshaft |
|
|
|
10 |
|
|
14341 |
1 |
范围档气缸活塞 |
Gear range cylinderpiston |
|
|
|
11 |
|
|
14345 |
1 |
〇型密封圈 |
O-ring |
|
|
|
12 |
|
|
14344 |
1 |
〇型密封圈 |
O-ring |
|
|
|
13 |
|
|
14349 |
1 |
气缸盖密封垫 |
Cylinder head gasket |
|
|
|
14 |
|
|
GB890-80 |
1 |
六角尼龙圈锁紧薄螺母 M16X1.5 |
Nut M16xl.5 |
|
|
|
15 |
|
|
F99857 |
1 |
副箱换档气缸盖 |
Sub-gearbox gear shifting cylinder head |
|
|
|
16 |
|
|
C03052 |
1 |
三通管接头NPT1/8 |
Three-way pipe joint |
|
|
|
17 |
|
|
Q618B01 |
1 |
方头锥形螺塞NPT1/8 |
Square head bevel plug |
|
|
|
18 |
|
|
12880 |
1 |
45°弯管接头 |
45° siphon joint |
|
|
|
19 |
|
|
X11511 |
4 |
褶皱铜垫圈 |
Draped copper washer |
|
|
|
20 |
|
|
79i.00.71.0069 |
1 |
压力开关 |
Pressure switch |
|
|
