1 |
|
|
Q1701032 |
2 |
六角头头部带孔螺栓Ml〇x32 |
Bolt Ml〇x32 |
|
|
|
2 |
|
|
GB93-76 |
2 |
弹簧垫圈10 |
Spring washer 10 |
|
|
|
3 |
|
|
GB5782-86 |
1 |
六角头螺栓Ml〇x32 |
Bolt Ml〇x32 |
|
|
|
4 |
|
|
F91409 |
4 |
一轴轴承盖 |
No 1 axle bearing head |
|
|
|
5 |
|
|
F91410 |
4 |
一轴轴承盖油封 |
No 1 axle bearing head oil seal |
|
|
|
6 |
|
|
14311 |
1 |
一轴轴承盖衬垫 |
No 1 axle bearing headgasket |
|
|
|
7 |
|
|
GB5783-86 |
1 |
小六角头螺栓M12X90 |
BoU M12x90 |
|
|
|
8 |
|
|
GB93-87 |
2 |
弹簧垫圈12 |
Spring washer 12 |
|
|
|
9 |
|
|
C01056 |
2 |
双头螺栓 |
Double head bolt |
|
|
|
10 |
|
|
GB95-85 |
5 |
垫圈16 |
Washer 10 |
|
|
|
11 |
|
|
GB889-80 |
6 |
六角尼龙圈锁紧螺母M16X1.5 |
Nut M16xl.5 |
|
|
|
12 |
|
|
9293 |
6 |
轴承回位弹簧 |
Bearing returning spring |
|
|
|
13 |
|
|
12817 |
2 |
离合器分离拨叉 |
Clutch throw-out shiftingfork |
|
|
|
14 |
|
|
X-7-603 |
1 |
六角头螺栓 |
Bolt |
|
|
|
15 |
|
|
996914 |
2 |
角接触型离合器分离球轴承 |
Angular contact clutch throw-out ball bearing |
|
|
|
16 |
|
|
4425 |
1 |
拉簧 |
Pull spring |
|
|
|
17 |
|
|
51016 |
2 |
油管总成 |
Oil pipe assembly |
|
|
|
18 |
|
|
12880 |
1 |
45°弯管接头 |
45° siphon joint |
|
|
|
19 |
|
|
C04002 |
1 |
离合器分离轴承座 |
Clutch throw-out bearinghousing |
|
|
|
20 |
|
|
Q701B45 |
1 |
弯颈式润脂嘴 |
Bent-neck lubrication grease nozzle |
|
|
|
21 |
|
|
15410 |
2 |
SAE1#离合器壳体 |
SAE1# Clutch hull |
|
|
|
22 |
|
|
GB5782-76 |
1 |
小六角头螺栓M12X38 |
Bolt M12x38 |
|
|
|
23 |
|
|
GB93-87 |
2 |
弹簧垫圈 |
Washer |
|
|
|
24 |
|
|
8677 |
2 |
离合器拨叉轴衬套 |
Clutch shifting fork shaft bushing |
|
|
|
25 |
|
|
X-6-11 |
1 |
半圆键 |
Semi-round key |
|
|
|
26 |
|
|
A-C04009-1 |
1 |
离合器分离拨叉轴总成 |
"Clutch throw-out shifting fork shaft |
|
|
